MSI MAG B650 TOMAHAWK WIFI DDR5 AMD AM5 ATX Motherboard (1)

MSI MAG B650 TOMAHAWK WIFI DDR5 AMD AM5 ATX Motherboard

Socket: AM5
Form Factor: ATX
Chipset: AMD B650
Memory Support: 4 x DDR5 DIMM slots, up to 128GB, up to 6400 MHz (OC)
Expansion Slots: 1 x PCIe 5.0 x16, 1 x PCIe 4.0 x16, 2 x PCIe 4.0 x1
Storage: 6 x SATA III ports, 2 x Lightning Gen 5 M.2 slots
Connectivity: USB 3.2 Gen 2×2 Type-C, USB 3.2 Gen 2, USB 3.2 Gen 1, HDMI, DisplayPort
Wireless: Wi-Fi 6E, Bluetooth 5.2

Compare

Original price was: 32,000৳ .Current price is: 30,800৳ .

Specification

Basic Information

Supported CPU	Supports AMD Ryzen 8000/ 7000 Series Desktop Processors Socket AM5
Chipset	AMD B650
Form Factor	ATX 243.84mmx304.8mm
Audio	Realtek ALC4080 Codec 7.1-Channel High Performance Audio , Supports S/PDIF output Supports up to 32-Bit/384 kHz playback on front panel

Expansion Slots

PCI	2x PCI-E x16 slot Support x16/ x4 1x PCI-E x1 slot , PCI_E1 PCIe 4.0 supports up to x16 (From CPU) PCI_E2 PCIe 4.0 supports up to x4 (From Chipset) PCI_E3 PCIe 3.0 supports up to x1 (From Chipset)

Memory

Memory Type	DDR 5
Memory Slots	4 DIMMs
Supported Memory	Memory Support DDR5 6600+(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz
Maximum Memory	128GB

Graphics

Graphics	1x HDMI 1x DisplayPort , Support HDMITM 2.1 with HDR, maximum resolution of 4K 60Hz Support DP 1.4, maximum resolution of 8K 60Hz

Connector & Ports

HDMI	1x HDMI
USB (s)	2x USB 2.0 (Rear) 4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) , 3x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Front) 1x USB 3.2 Gen2x2 Type C (Rear)
LAN Port (s)	Realtek RTL8125B 2.5Gbps LAN
Wireless Communication module	AMD Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX , Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands Supports 802.11 a/ b/ g/ n/ ac/ ax , Supports Bluetooth 5.2
Supported Storage	3x M.2 slot M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_2 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices , M.2_3 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 6x SATA 6G port
RAID	Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
Audio Jack	Audio Connectors
Internal I/O Ports	1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 6x System Fan , 2x Addressable V2 RGB LED connector (JARGB_V2) 2x RGB LED connector(JRGB) 4x USB 2.0 2x USB 3.2 Gen1 Type A 1x USB 3.2 Gen2 Type C , 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH)
TPM (Trusted Platform Module )	1x TPM pin header(Support TPM 2.0)

Others

Special Features	4x EZ Debug LED

Warranty Information

Manufacturing Warranty	03 years

Description

MSI MAG B650 TOMAHAWK WIFI DDR5 AMD AM5 ATX Motherboard

Elevate your PC build to new heights with the MSI MAG B650 TOMAHAWK WIFI DDR5 AMD AM5 ATX Motherboard. Engineered for gamers, creators, and tech enthusiasts, this high-performance motherboard combines cutting-edge technology, unmatched durability, and exceptional connectivity features. With full support for AMD Ryzen processors and DDR5 memory, it provides the perfect foundation for a next-generation powerhouse.

Key Features

1. Designed for AMD Ryzen AM5 Processors

Built around the AMD B650 chipset, the MAG B650 TOMAHAWK is ready to support the latest Ryzen processors. Its AM5 socket ensures compatibility with cutting-edge CPUs, allowing you to unlock the full potential of your PC for gaming, content creation, and multitasking.

2. Advanced DDR5 Memory Support

Experience faster load times, enhanced bandwidth, and improved performance with support for DDR5 memory. This motherboard offers optimized memory profiles and increased stability for demanding applications and games.

3. PCIe 4.0 and Lightning-Fast Storage

Equipped with PCIe 4.0 slots, the MAG B650 TOMAHAWK delivers unmatched speeds for GPUs and SSDs. It includes multiple M.2 slots with support for NVMe SSDs, ensuring blazing-fast storage performance for quick system boot-ups and rapid file transfers.

4. Built-in Wi-Fi 6E and Bluetooth 5.2

Stay connected with the latest wireless technology. With Wi-Fi 6E, you get faster and more reliable internet connections, while Bluetooth 5.2 ensures seamless connectivity with your peripherals, making it ideal for modern smart setups.

5. Comprehensive Cooling Solutions

Keep your system cool under pressure with MSI’s advanced thermal design, which includes:

Premium heatsinks and thermal pads to dissipate heat efficiently.
Multiple fan headers for precise cooling customization.
Compatibility with liquid cooling solutions for enthusiasts.

6. High-Quality Audio and Immersive Gaming

The motherboard’s high-definition audio chipset delivers crisp, clear sound, perfect for immersive gaming and entertainment. Paired with support for multi-channel surround sound, it enhances your gaming and media experience.

7. Enhanced Build Quality and Durability

Built to last, the MAG B650 TOMAHAWK features:

A 6-layer PCB for improved signal reliability.
Steel-reinforced PCIe slots to handle heavy GPUs.
Military-grade components for consistent, stable operation.

8. Intuitive BIOS and Software

Customize and optimize your system with MSI’s user-friendly BIOS interface and exclusive software, including:

MSI Center for real-time system monitoring.
Memory Boost and Game Boost for performance tweaks.
Secure boot and TPM support for enhanced security.

Why Choose the MSI MAG B650 TOMAHAWK WIFI?

The MSI MAG B650 TOMAHAWK WIFI DDR5 AMD AM5 ATX Motherboard is the ultimate choice for anyone seeking peak performance, reliability, and style. Its extensive features cater to gamers, creators, and professionals, ensuring a seamless and efficient computing experience.

Key Benefits:

Supports AMD Ryzen AM5 processors for future-ready performance.
Fast DDR5 memory and PCIe 4.0 support for unmatched speed.
Advanced connectivity with Wi-Fi 6E and Bluetooth 5.2.
Premium cooling solutions for consistent system stability.
Durable design with military-grade components.

Perfect for Your High-Performance PC Build

Whether you’re a gamer seeking smooth frame rates, a creator needing fast rendering speeds, or an enthusiast aiming for a sleek and powerful build, the MSI MAG B650 TOMAHAWK WIFI DDR5 AMD AM5 ATX Motherboard delivers everything you need.
