MSI PRO B650M-P DDR5 AMD AM5 mATX Motherboard

  • Socket: AM5
  • Form Factor: mATX
  • Chipset: AMD B650
  • Memory Support: 2 x DDR5 DIMM slots, up to 64GB, up to 5600 MHz (OC)
  • Expansion Slots: 1 x PCIe 4.0 x16, 1 x PCIe 3.0 x1
  • Storage: 4 x SATA III ports, 1 x M.2 slot (PCIe 4.0 x4)
  • Connectivity: USB 3.2 Gen 2, USB 3.2 Gen 1, HDMI, DisplayPort
Compare

Original price was: 16,500৳ .Current price is: 15,800৳ .

Specification
Description
Review

Specification

Basic Information

Supported CPU

Supports AMD Ryzen 9000/8000/7000 Series Desktop Processors Socket AM5
Chipset

AMD B650
Form Factor

mATX 243.84mmx243.84mm
Audio

Realtek ALC897 Codec 7.1-Channel High Definition

Expansion Slots

PCI

1x PCI-E x16 slot 2x PCI-E x1 slot

,

PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset)

Memory

Memory Type

DDR 5
Memory Slots

4 DIMMs
Supported Memory

Max. overclocking frequency: • 1DPC 1R Max speed up to 7200+ MHz • 1DPC 2R Max speed up to 6000+ MHz • 2DPC 1R Max speed up to 6000+ MHz • 2DPC 2R Max speed up to 5400+ MHz

,

Memory Support DDR5 7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz

,

Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports AMD EXPO
Maximum Memory

192GB

Graphics

Graphics

Support HDMITM 2.1, maximum resolution of 4K 60Hz* Supports DP 1.4, maximum resolution of 4K 60Hz* Support VGA, maximum resolution of 1920×1200 60Hz*

Connector & Ports

HDMI

1x HDMI
USB (s)

2x USB 3.2 Gen1 Type A (Front) 2x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Front)

,

4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 3.2 Gen1 Type A (Rear)
LAN Port (s)

Realtek 8125BG 2.5G LAN
Supported Storage

2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices

,

M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G
RAID

Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
Audio Jack

1x Front Audio (JAUD)

,

Back Audio connectors
Internal I/O Ports

1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan

,

2x Addressable V2 RGB LED connector (JARGB_V2) 2x RGB LED connector(JRGB) 4x USB 2.0 ports

,

2x USB 3.2 Gen1 Type A ports 1x USB 3.2 Gen2 Type C ports

,

3x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM)
TPM (Trusted Platform Module )

1x TPM pin header(Support TPM 2.0)

Others

Special Features

4x EZ Debug LED

Warranty Information

Manufacturing Warranty

03 years

Description

MSI PRO B650M-P DDR5 AMD AM5 mATX Motherboard

The MSI PRO B650M-P DDR5 AMD AM5 mATX Motherboard is a feature-packed platform designed to meet the demands of professionals, gamers, and PC enthusiasts. Built with the latest AMD B650 chipset and AM5 socket, it delivers exceptional performance and future-ready support for Ryzen processors. With DDR5 memory compatibility, PCIe 4.0 support, and a compact micro-ATX form factor, this motherboard is perfect for efficient and high-performance PC builds.

Key Features

1. AMD Ryzen AM5 Processor Ready

The MSI PRO B650M-P is equipped with an AM5 socket to support the latest AMD Ryzen processors, enabling powerful performance for multitasking, gaming, and productivity tasks. Its advanced design ensures seamless compatibility with future AMD Ryzen upgrades.

2. Next-Generation DDR5 Memory

Unlock the full potential of DDR5 memory technology with the PRO B650M-P. Experience faster data transfer rates, improved system responsiveness, and enhanced multitasking. The motherboard supports overclocking, giving enthusiasts greater control over their system performance.

3. PCIe 4.0 for High-Speed Components

Take advantage of PCIe 4.0 technology for blazing-fast data transfer rates and enhanced performance. The PRO B650M-P includes M.2 slots for NVMe SSDs, allowing you to build a system with ultra-fast storage for quick boot times and efficient workflows.

4. Compact Micro-ATX Form Factor

Designed with a space-saving micro-ATX form factor, this motherboard is ideal for compact and mid-sized PC builds. Despite its smaller size, it provides ample connectivity and expansion options to meet diverse user needs.

5. Comprehensive Connectivity Options

Stay connected with modern and versatile connectivity features, including:

  • USB 3.2 Gen 1 and USB 2.0 ports for peripherals and fast data transfer.
  • Gigabit Ethernet for stable and high-speed wired internet connections.
  • Multiple display outputs, including HDMI and DisplayPort, for multi-monitor setups.

6. Efficient Cooling Solutions

Maintain system stability with MSI’s advanced cooling design, featuring:

  • Optimized fan headers for flexible cooling configurations.
  • Integrated temperature sensors to monitor and manage system thermals.

7. Durable Build and High-Quality Components

Built for reliability, the MSI PRO B650M-P features:

  • Steel-reinforced PCIe slots to support heavy graphics cards.
  • 6-layer PCB construction for improved thermal performance and signal integrity.
  • Military-grade components for dependable performance in demanding environments.

8. User-Friendly BIOS and Optimization Tools

MSI’s intuitive BIOS and software tools make system setup and customization simple. With features like Memory Boost and Core Boost, users can fine-tune their systems for optimal performance and stability.

9. Ideal for Professionals and Creators

The PRO B650M-P is designed with business and productivity users in mind. With support for TPM (Trusted Platform Module), it ensures data security, making it a great choice for professional workstations.

Why Choose the MSI PRO B650M-P DDR5?

The MSI PRO B650M-P DDR5 AMD AM5 mATX Motherboard strikes the perfect balance of performance, durability, and value. Whether you’re building a high-performance workstation, a reliable home office PC, or a compact gaming rig, this motherboard provides all the essential features you need.

Key Benefits:

  • Full support for AMD Ryzen AM5 processors.
  • Next-gen DDR5 memory compatibility for superior speed and performance.
  • Compact mATX design for small and efficient PC builds.
  • PCIe 4.0 and M.2 slots for fast storage and enhanced graphics.
  • Durable build quality with premium materials and components.

Build a Reliable, Future-Ready PC Today

With its advanced features, durable design, and compact form factor, the MSI PRO B650M-P DDR5 AMD AM5 mATX Motherboard is an excellent choice for modern PC builders. Elevate your computing experience with the performance, reliability, and versatility this motherboard offers.
