ASUS B760M-AYW D4 mATX With WiFi Motherboard

Chipset: Intel B760
CPU Support: Intel 12th and 13th Gen Core processors (LGA1700)
Memory: 4 x DDR4 DIMM slots, up to 128GB, 5333MHz (OC)
Storage: Multiple M.2 NVMe slots, SATA 6Gbps ports
Expansion Slots: PCIe 4.0 x16, PCIe 3.0 x1
WiFi: WiFi 6 onboard

Compare

Original price was: 21,000৳ .Current price is: 19,200৳ .

Specification

Basic Information

Supported CPU	Intel Socket LGA1700 for Intel Core 14th & 13th Gen Processors, Intel Core 12th Gen, Pentium® Gold and Celeron Processors , Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
Chipset	Intel B760 Chipset
BIOS	128 Mb Flash ROM , UEFI AMI BIOS
Form Factor	mATX Form Factor 9.6 inch x 8.3 inch (24.4cm x 21.1cm)
Audio	A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. , Audio Features , Audio Shielding , Dedicated audio PCB layers , Premium audio capacitors , Realtek 7.1 Surround Sound High Definition Audio CODEC , Supports up to 24-Bit/192 kHz playback , Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking

Expansion Slots

PCI	1 x PCIe 4.0 x16 slot , 2 x PCIe 4.0 x1 slots , Intel B760 Chipset , Intel Core Processors (14th & 13th & 12th Gen)

Memory

Memory Type	DDR4
Memory Slots	2 x DIMM
Supported Memory	5333(OC)/5066(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/ 4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/ 3400(OC)/3333(OC)/3200/3000/2933/2800/2666/ 2400/2133 Non-ECC, Un-buffered Memory , Dual Channel Memory Architecture , Supports Intel® Extreme Memory Profile (XMP)
Maximum Memory	64GB

Graphics

Graphics	1 x HDMI port , Graphics specifications may vary between CPU types , Supports 4K@60Hz as specified in HDMI 2.1

Connector & Ports

HDMI	1 x HDMI
Wireless Communication module	Bluetooth® v5.2 , Supports 2.4/5GHz frequency band , Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
RAID	Intel Rapid Storage Technology supports SATA RAID 0/1/5/10
Audio Jack	3 x audio jacks
Internal I/O Ports	1 x 10-1 pin System Panel header , 1 x 24-pin Main Power connector , 1 x 4-pin Chassis Fan header , 1 x 4-pin CPU Fan header , 1 x 8-pin +12V Power connector , 1 x Aura RGB header , 1 x Clear CMOS header , 1 x COM Port header , 1 x Front Panel Audio header (AAFP) , 1 x S/PDIF Out header , 1 x Speaker header , 1 x SPI TPM header (14-1pin) , 1 x USB 2.0 header supports 2 additional USB 2.0 ports , 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports , 2 x Addressable Gen 2 headers , 2 x M.2 slots (Key M) , 4 x SATA 6Gb/s ports , Fan and Cooling related , Power related , Storage related
TPM (Trusted Platform Module )	1 x SPI TPM header (14-1pin)

Others

Special Features	ASUS 5X PROTECTION III – DIGI+ VRM – LANGuard – Overvoltage Protection – SafeSlot Core – Stainless-Steel Back I/O , ASUS EZ DIY – ProCool , ASUS Q-Design – Q-DIMM – Q-LED Core – Q-Slot , ASUS Thermal Solution – VRM heatsink design , Aura Sync – Aura RGB header – Addressable Gen 2 headers
Bundled Software	AI Suite 3 – DIGI+ VRM – PC Cleaner , Armoury Crate – Aura Sync – Fan Xpert – Power Saving , ASUS CPU-Z , ASUS Exclusive Software , ASUS EZ DIY – ASUS CrashFree BIOS 3 – ASUS EZ Flash 3 – ASUS UEFI BIOS EZ Mode , MyASUS , Norton 360 Deluxe (60 Days Free Trial) , UEFI BIOS , WinRAR

Warranty Information

Manufacturing Warranty	03 years

Description

ASUS B760M-AYW D4 mATX With WiFi Motherboard – Unleash the Power of Cutting-Edge Performance

The ASUS B760M-AYW D4 mATX With WiFi Motherboard is a premium choice for building powerful and reliable PCs, whether for gaming, productivity, or creative workloads. Engineered for versatility and efficiency, this Micro-ATX motherboard is packed with advanced features to unlock the full potential of your system. With support for the latest 12th and 13th Gen Intel processors, DDR4 memory, and integrated WiFi connectivity, it offers the perfect blend of performance, durability, and convenience.

Key Features of ASUS B760M-AYW D4 mATX With WiFi Motherboard

12th and 13th Gen Intel Processor Support:
Built with an Intel B760 chipset, this motherboard ensures seamless compatibility with the latest Intel Core, Pentium Gold, and Celeron processors. It maximizes CPU performance for both gaming and multitasking.
High-Speed DDR4 Memory Support:
Equipped with 4 DIMM slots, it supports up to 128GB of DDR4 memory with speeds of up to 5333MHz (OC). This ensures faster loading times, enhanced multitasking, and smooth performance.
Integrated WiFi Connectivity:
Features onboard WiFi 6, providing fast, reliable, and low-latency wireless networking for online gaming, streaming, and productivity without the need for additional adapters.
PCIe 4.0 Expansion Slots:
Includes PCIe 4.0 x16 slots for high-speed data transfer and compatibility with the latest graphics cards, ensuring excellent gaming and rendering performance.
Comprehensive Cooling Solutions:
Advanced cooling options with multiple fan headers and optimized thermal design ensure stable performance even during intensive workloads.
M.2 NVMe SSD Support:
Features multiple M.2 slots for ultra-fast storage, supporting PCIe 4.0 drives for faster boot times and application load speeds.
Robust Connectivity Options:
- USB Ports: Multiple USB 3.2 Gen 1 and USB 2.0 ports for versatile peripheral connectivity.
- LAN Port: Gigabit Ethernet for stable wired network performance.
- Audio Jacks: High-definition audio for immersive sound experiences.
Durable and Reliable Build:
ASUS quality assurance ensures premium components, enhanced power delivery, and long-lasting durability for a reliable PC build.
Compact mATX Form Factor:
Designed for smaller PC cases without compromising on functionality, making it ideal for space-conscious users who demand performance.

Why Choose ASUS B760M-AYW D4 mATX Motherboard?

Optimized for Gamers and Creators: High-speed memory, PCIe 4.0 support, and onboard WiFi provide the tools needed for smooth gaming and creative tasks.
Reliable and Future-Proof: Built to handle the latest technologies with upgrade options for future-proofing your system.
Efficient Cooling Design: Keeps your components cool and operational, even during demanding applications.
Compact Yet Powerful: The mATX form factor offers exceptional performance in a smaller, space-saving design.

Perfect for Custom PC Builds

Whether you’re building a high-performance gaming rig, a workstation for demanding tasks, or a versatile home PC, the ASUS B760M-AYW D4 mATX With WiFi Motherboard offers unmatched reliability and performance. Its cutting-edge features make it an excellent foundation for modern computing needs.

Buy the ASUS B760M-AYW D4 mATX Motherboard at Star Computer

Available now at Star Computer, your trusted destination for premium PC components. Experience the next level of performance and connectivity with this feature-packed motherboard.

Upgrade your PC today with the ASUS B760M-AYW D4 mATX Motherboard – Order now and unlock the power of innovation!
